Checchi & Magli Transplanters

Top 24 Transplanter


The Top 24is a semi-automatic seedling transplanter for square and pyramid-shaped cells, and plants up to 6 cm in diameter, typically used for the planting of Cabbage, Cauliflower, Broccoli, Lettuce, Silver beet, Leeks, Tomato, Celery, Cucumber, Zucchini, Pumpkin.



Top 24

Photograph for illustration purposes - standard specifications may not match those shown.

The transplanter is a modular design.  Each Dual transplanter unit is mounted on a tool bar.  The transplanter machine is configured for planting 2,4, and 6 rows by mounting the desired number of transplanter modules onto a suitably sized tool bar with the module positioned at the desired inter-row spacing.  The tool bar incorporates a driveline which is powered by ground-engaging wheels which ensure the transplanter operation is synchronised with ground travel.  The inter-plant distance is set by the selected gear setting in the driveline mechanism.

FEATURES OF THE CHECCHI & MAGLI TOP 24 TRANSPLANTER

DISTRIBUTOR

Top 24 distributor
  • 24 Cup Distributor for high productivity
  • 5000/8000 plants per hour per operator
TOP 24 ROTARY
  • Rotary Tray holder 6 tray capacity

DRIVELINE

The ground-engaged wheel provides the driving mechanism for the transplanter system ensuring each planting action is accurately synchronised with the ground travel along the planting beds.
Drive Wheel
  • Ground wheels carry the weight of the machine and drive the planting operation.
Clutch
Hex Drive Shaft
  • Overload safety clutch on driveline protects the entire machine and the planting mechanism if plants or cell material block the machine.
  • Once the blockage has been cleared the safety clutch auto-resets to restart the operation.





  • Heavy duty 22mmHex Drive Shaft across machine.

PLANTING UNIT

The planting unit is mounted on the tool bar with a parallelogram which provides a tension to counter-balance the weight of the planter, reducing ground pressure, which enables the planter to consistently float along the plant bed. The front press wheel firms the planting zone before the ploughshare creates the furrow into which the seedling is planted.

The gentle floating of the planter on the soil ensures accurate and consistent planting depth. The plant is dropped from the distributor into the planting ploughshare. The plant is held vertical in the ploughshare between a front curtain and the kicker. The planting mechanism is synchronised with the ground travel to accurately maintain the pre-set inter-plant spacing and the timing of the raising of the curtain and the pushing of the seedling by the kicker into the furrow in a smooth coordinated action. The trailing packing wheels then press the soil around the seedling.

Top 24 Parallelgram
  • Transplant units float independently on a high range Parallelogram to follow ground contour.
  • The tension is adjustable to counter balance the planter and operator.
Front Press Wheel
  • Adjustable Front Press Wheel.
  • Optional disc Kit for High Trash - is shown between front press wheel and ploughshare.
  • Optional clod seperator can be fitted before the ploughshare.
Swing Shoe
  • Swing down ploughshare for easy cleaning of soil build up from the seedling cells.
Kicker
  • The plant is held in upright until it is pushed into the furrow.
  • Plant is pushed into the furrow in a smooth action with the raising of the curtain and swing of the kicker.
Adjustable wheel
  • 3 way adjustment on the trailing packing wheels for all soil conditions
  • The packing wheels maintain accurate planting depth
Rubber Packing Wheels
  • Alternative Rubber packing wheels for wet, sticky soil.

APPLICATIONS

applications Suitable for
  • Large and small seedlings
  • Capsicum
  • Eggplant
  • Zucchini
  • Tomato
  • Large seeds
  • Bulbs

Diagram
  • Adjustable from 60cm-120cm between the rows
  • 15-50 cm between the plants (32-85cm optimal)

OPTIONS

Packing Skid
  • Skid - which assists the planter to float over very soft or dry soil types.
Show Sizes
  • Different width Ploughshares are available to suit the seedling cell size.
Shelf

  • 2 and 6 Shelf Tray holders.
Fertliser
  • Fertiliser Device for Easy Fertiliser Application.
Watering attachement
  • Irrigation Drip Tape Layer.

SPECIFICATIONS

TOP 24
2 ROW
TOP 24
4 ROW
TOP 24
6 ROW
LENGTH
220
220
220
WIDTH
200
350
500
MIN HP
40
60
80
WEIGHT
665
1080
1550

BROCHURE

Click this link to download a brochure.
Please note that Australian specifications may vary to those shown on the manufacturer's brochure and website.
Follow this link to the manufacturer's website (Checchi and Magli)
